Marine & Offshore Communication Cable With Inner Sheath (Individual Screen)

Product: Marine & Offshore Communication Cable With Inner Sheath (Individual Screen)

Marine & Offshore Communication Cable With Inner Sheath (Individual Screen)

Categories Instrumentation / Telephone Cable, Marine Shipboard Cable

Type: CHJPJP85/SC / CHJPJP95/SC / CHJPFP/SC / CHJPFP86/SC / CHJPFP96/SC

Application: Armoured Instrumentation or Communication cable with individual screened for fixed installation in most area and on open deck in ships and offshore units. Similar to TICI(I), TIOI(I) etc.

Rated Voltage: 150/250V

Max. Conductor Temperature: 90°C

Share This Items :

Conductor:	CH	Tinned stranded annealed copper conductor, Class 2 or Class5, IEC60228
Insulation:	J	XLPE, IEC60092-360
Ovr. Screen:		Alum. Foil tape 100% coverage with tinned drain wire (Optional)
Inner Sheath:	PJ	Halogen free flame-retardant thermoset compound (SHF2)
	PF	Halogen free flame-retardant thermoplastic compound (SHF1)
Pair Screen:	P	Alum. Foil tape 100% coverage with tinned drain wire
Armour:	8	Tinned copper wire braid
	9	Galvanised steel wire braid
Outer Sheath:	5	Halogen free flame-retardant thermoset compound (SHF2)
	6	Halogen free flame-retardant thermoplastic compound (SHF1)
	SC	Flame retardant IEC60332-1-2 and IEC60332-3-22 Cat A
